Electrical parameters:

1.Frequency range: 2400-2500MHz 5150-5850MHz

2.Polarization: 2*vertical

3.Gain:10±0.5dbi(2400-2500MHz) 12±0.5dbi(5150-5850MHz)

4.Beam width: Horizontal 65±5°, vertical 65±3°

5.Front-to-back ratio: ≥23dB

6.VSWR: ≤2.0

7.Isolation degree: ≥22dB

8.Input impedance: 50Ω

9.Power capacity: 100W

10.Anti-lightning protection: DC ground

Basic mechanical performance:

1.  Product category: N-J

2.Size (without packet):220*220*30mm

3.Weight (without packet):1.2kg

4.Antenna shield material: ABS

5.Reflection board material: Aluminum / copper

6.Antenna shield color: white

7.Operating temperature: -30~+50℃

8.Operating humidity: <95%

9.Wind resistance: 36.9m/s

10.Pole mounted: ￠40~￠55

Product feature:

Wider frequency band, better connectivity, symmetrical main lobe, strong anti-interference ability, convenient site construction and easy maintenance.
